Description
| Overall Size | 2895*1120*1320mm |
| Cargo Box Type | 280mm cargo box |
| Cargo Box Size | 1400*1050*280mm |
| Motor Type | DC/square wave/magnetic steel height 50H |
| Rated Power | 1000W |
| Peak Power | 2700W |
| Transmitting Mode | Gear transmitted |
| Controller | 18 tubes controller |
| Max. Current | 45A |
| Front Suspension | Duplex/φ33mm/hydraulic/absorber |
| Rear Suspension Type | Leaf spring |
| Rear Shock Absorber | / |
| Rear Axle | Taper/ratio: high speed 8.22:1 low speed:22:1/tube:φ60mm/thickness:4mm/power gearbox |
| Min. Turning Radius | 6500mm |
| Min. Ground Clearance | 150mm |
| Leaf Spring | 5pcs/width:45mm/thickness:5mm |
| Tyre (F/R) | Front:80/100-14 steel; Rear:3.75- 12 steel |
| Brake Type | Mechanical brake |
| Brake Mode | Drum/drum |
| Max. Speed | 26km/h |
| Battery | 60V/45Ah/maintenance-free battery |
| Mileage Per Charge | 50km |
| Charging Time | 8-10 hours |
| Curb Weight | 265kg |
| Rated Gross Weight | 465kg |
| Max. Designed Gross Weight | 565kg |
| 40HQ Container Packing Qty. | CKD 66 sets |
| Features | 1.All lights are with EEC certification 2.Front seat equipped with off-seat alarm 3.Front and rear wheel are linkage brake for better braking performance 4.Bigger tourque with variable gear axle 5.More loading capacity with thicker frame 6.Shift lever on left hand postion is easy to handle 7.The carriage is equipped with pneumatic struts, convenient for lifting and maintenance 8.The shock absorber is equipped with a dust cover device to effectively prevent dust and reduce shock wear |
